Volume pricing
- 1+ pcs$11.23
- 10+ pcs$10.59
- 100+ pcs$9.99
- 500+ pcs$9.43
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Shape
- Square
- Iec Conformance
- NO
- Depth
- 4mm
- Contact Type
- Forked
- JESD-609 Kodu
- e3
- Mil Conformance
- NO
- Current Rating Amps
- 4.5A per Contact
- Connector Type
- Elevated Socket
- Contact Finish Thickness Mating
- 3.00μin 0.076μm
- Contact Materials
- Phosphor Bronze
- Number Of Positions Loaded
- All
- Housing Color
- Black
- Terminal
- Solder
- Pitch Mating
- 0.079 2.00mm
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Yayın Yılı
- 2000
- Sıra Sayısı
- 2
- Contact Finish Mating
- Gold
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Pozisyon Sayısı
- 50
- Uzunluk
- 50.3mm
- Gender
- Receptacle
- Din Conformance
- NO
- Orientation
- Straight
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Resistance
- 10mOhm
- Ambalaj
- Tube
- Style
- Board to Board or Cable
- Material Flammability Rating
- UL94 V-0
- Çalışma Sıcaklığı
- -55°C~125°C
- Fastening Type
- Push-Pull
- Kurşunsuz Kodu
- yes
- Row Spacing Mating
- 0.079 (2.00mm)
- Contact Length Post
- 0.350 8.89mm
- Radyasyon Dayanımı
- No
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Seri
- ESQT
- Option
- GENERAL PURPOSE
