ESQ-132-39-G-D

Specifications

Orientation

Straight

Contact Materials

Phosphor Bronze

Polarization Key

POLARIZED HOUSING

Iec Conformance

NO

Nem Hassasiyeti (MSL)

1 (Unlimited)

Gender

Receptacle

Kurşunsuz Kodu

yes

Insulation Materials

Liquid Crystal Polymer (LCP)

Number Of Pcb Rows

2

Radyasyon Dayanımı

No

Contact Finish Thickness Mating

20.0μin 0.51μm

Number Of Positions Loaded

All

Additional Feature

LOW INSERTION FORCE

Akım Değeri

6.9A

Reference Standard

UL, CSA

Option

GENERAL PURPOSE

JESD-609 Kodu

e4

Body Breadth

0.195 inch

Pcb Contact Pattern

RECTANGULAR

Filter Feature

NO

Montaj Tipi

Through Hole

Seri

ESQ

Pozisyon Sayısı

64

Pitch Mating

0.100 2.54mm

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Din Conformance

NO

Housing Color

Black

Material Flammability Rating

UL94 V-0

Max Voltage Rating Ac

550V

Housing Material

Polyester

Max Current Rating

6.9A

Style

Board to Board

Mating Contact Pitch

0.1 inch

Sıra Sayısı

2

Contact Finish Thickness Post

3.00μin 0.076μm

Depth

4.95mm

Current Rating Amps

5.7A per Contact

Insertion Forcemax

.9174 N

Connector Type

Elevated Socket

RoHS Durumu

ROHS3 Compliant
