Volume pricing
- 1+ pcs$3.29
- 10+ pcs$3.10
- 100+ pcs$2.93
- 500+ pcs$2.76
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mixed Contacts
- NO
- Contact Shape
- Square
- Uzunluk
- 10.67mm
- Contact Type
- Forked
- Parça Durumu
- Active
- Fastening Type
- Push-Pull
- Nominal Gerilim
- 550VAC
- Contact Resistance
- 10mOhm
- Fabrika Tedarik Süresi
- 6 Weeks
- Montaj
- Through Hole
- Yayın Yılı
- 2000
- Row Spacing Mating
- 0.100 (2.54mm)
- Reliability
- COMMERCIAL
- Çalışma Sıcaklığı
- -55°C~125°C
- RoHS Durumu
- ROHS3 Compliant
- Ambalaj
- Tube
- Connector Type
- Elevated Socket
- Mil Conformance
- NO
- Contact Length Post
- 0.190 4.83mm
- Contact Finish Mating
- Gold
- Number Of Conductors
- ONE
- Terminal
- Solder
- Insulation Height
- 0.535 13.60mm
- Material Flammability Rating
- UL94 V-0
- Housing Color
- Black
- Housing Material
- Polyester
- Max Voltage Rating Ac
- 550V
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Pitch Mating
- 0.100 2.54mm
- Pozisyon Sayısı
- 8
- Seri
- ESQ
- Din Conformance
- NO
- Montaj Tipi
- Through Hole
- Filter Feature
- NO
- JESD-609 Kodu
- e4
- Pcb Contact Pattern
- RECTANGULAR
- Body Breadth
- 0.195 inch
- Depth
- 4.95mm
- Current Rating Amps
- 5.7A per Contact
- ECCN Kodu
- EAR99
