Specifications
- Özellikler
- Keying Slot
- Mil Conformance
- NO
- Style
- Board to Cable/Wire
- Kurşunsuz Kodu
- yes
- Radyasyon Dayanımı
- No
- Row Spacing Mating
- 0.050 (1.27mm)
- Number Of Positions Loaded
- All
- Montaj
- Surface Mount
- Connector Type
- Header
- Housing Color
- Black
- Reliability
- COMMERCIAL
- Din Conformance
- NO
- Contact Shape
- Square
- Fastening Type
- Push-Pull
- Fabrika Tedarik Süresi
- 3 Weeks
- Mixed Contacts
- NO
- Orientation
- Straight
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Total Number Of Contacts
- 10
- Seri
- ESHF
- Parça Durumu
- Active
- HTS Kodu
- 8536.69.40.40
- Contact Finish Post
- Tin
- Contact Materials
- Phosphor Bronze
- Pozisyon Sayısı
- 10
- Depth
- 5.59mm
- Ambalaj
- Tube
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Terminal
- Solder
- Contact Lengthmating
- 0.120 3.05mm
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Finish Mating
- Gold
- RoHS Durumu
- ROHS3 Compliant
- Max Current Rating
- 3A
- Gender
- Male
- Option
- GENERAL PURPOSE
- Housing Material
- Polymer
- Mating Contact Pitch
- 0.05 inch
- Pcb Contact Pattern
- RECTANGULAR
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
