Volume pricing
- 1+ pcs$5.67
- 10+ pcs$5.35
- 100+ pcs$5.05
- 500+ pcs$4.76
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Bulk
- Connector Type
- Elevated Socket
- Material Flammability Rating
- UL94 V-0
- Radyasyon Dayanımı
- No
- Fabrika Tedarik Süresi
- 3 Weeks
- Reach Svhc
- No SVHC
- Montaj Tipi
- Through Hole
- Contact Length Post
- 0.153 3.89mm
- Orientation
- Straight
- Contact Finish Post
- Tin
- Pitch Mating
- 0.100 2.54mm
- Gender
- Receptacle
- Yayın Yılı
- 2014
- Contact Shape
- Circular
- Contact Finish Mating
- Gold
- Uzunluk
- 20.32mm
- Option
- GENERAL PURPOSE
- Iec Conformance
- NO
- Row Spacing Mating
- 0.100 (2.54mm)
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- RoHS Durumu
- ROHS3 Compliant
- Insulation Color
- Black
- Style
- Board to Board
- HTS Kodu
- 8536.69.40.40
- Mil Conformance
- NO
- Number Of Positions Loaded
- All
- Sıra Sayısı
- 2
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Housing Material
- Polyester
- Kurşunsuz Kodu
- yes
- Max Current Rating
- 1A
- Contact Resistance
- 10mOhm
- Contact Materials
- Beryllium Copper
- Insulation Height
- 0.300 7.62mm
- ECCN Kodu
- EAR99
- Pozisyon Sayısı
- 16
- Depth
- 5.08mm
- Terminal
- Solder
- Fastening Type
- Push-Pull
