Volume pricing
- 1+ pcs$6.71
- 10+ pcs$6.33
- 100+ pcs$5.97
- 500+ pcs$5.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mounting Option1
- LATCH & EJECT
- Fabrika Tedarik Süresi
- 3 Weeks
- Plating Thickness
- FLASH inch
- Total Number Of Contacts
- 26
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- Straight
- Mixed Contacts
- NO
- HTS Kodu
- 8536.69.40.40
- Contact Finish Post
- Tin
- Parça Durumu
- Active
- Body Breadth
- 0.39 inch
- Seri
- EJH
- Pozisyon Sayısı
- 26
- Mounting Option2
- LATCHING
- Contact Materials
- Phosphor Bronze
- Özellikler
- Board Lock, Keying Slot
- Mil Conformance
- NO
- Style
- Board to Cable/Wire
- Number Of Positions Loaded
- All
- Row Spacing Mating
- 0.100 (2.54mm)
- Kurşunsuz Kodu
- yes
- Board Mounting Option
- SPLIT BOARD LOCK
- Connector Type
- Header
- Din Conformance
- NO
- Contact Shape
- Square
- Fastening Type
- Latch Lock/Eject Hooks
- Reliability
- COMMERCIAL
- Filter Feature
- NO
- Current Rating Amps
- 3A
- Contact Finish Thickness Mating
- 3.00μin 0.076μm
- Shrouding
- Shrouded - 4 Wall
- Polarization Key
- CTR W/GUIDE SLOTS
- Yayın Yılı
- 2013
- Contact Type
- Male Pin
- Insulation Height
- 0.500 12.70mm
- ECCN Kodu
- EAR99
- Uzunluk
- 50.65mm
- Montaj Tipi
- Surface Mount
- Iec Conformance
- NO
- Number Of Conductors
- ONE
