Volume pricing
- 1+ pcs$15.98
- 10+ pcs$15.07
- 100+ pcs$14.22
- 500+ pcs$13.42
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Insulation Height
- 0.300 7.62mm
- Reference Standard
- UL
- Reliability
- COMMERCIAL
- Additional Feature
- NONE
- Row Spacing Mating
- 0.079 (2.00mm)
- Terminal
- Solder
- Contact Materials
- Phosphor Bronze
- Connector Type
- Header
- Pozisyon Sayısı
- 44
- Çalışma Sıcaklığı
- -55°C~125°C
- Sıra Sayısı
- 2
- Contact Shape
- Square
- Current Rating Amps
- 3A
- Contact Finish Mating
- Gold
- Polarization Key
- CTR W/GUIDE SLOTS
- Style
- Board to Cable/Wire
- Shrouding
- Shrouded - 4 Wall
- Pcb Contact Pattern
- RECTANGULAR
- Body Depth
- 0.519 inch
- Ambalaj
- Tube
- Contact Finish Post
- Tin
- ECCN Kodu
- EAR99
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Insulation Color
- Black
- Contact Length Post
- 0.120 3.05mm
- HTS Kodu
- 8536.69.40.40
- Body Breadth
- 0.3 inch
- JESD-609 Kodu
- e3
- Contact Type
- Male Pin
- Number Of Positions Loaded
- 43
- Montaj Tipi
- Through Hole, Right Angle
- Contact Lengthmating
- 0.120 3.05mm
- Fastening Type
- Latch Lock/Eject Hooks
- Number Of Conductors
- ONE
- Number Of Pcb Rows
- 2
- Pitch Mating
- 0.079 2.00mm
- Parça Durumu
- Active
- Özellikler
- Keying Slot
- Gender
- Male
- Material Flammability Rating
- UL94 V-0
