Specifications
- Fabrika Tedarik Süresi
- 6 Weeks
- Reach Svhc
- No SVHC
- Seri
- EHT
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Mating Contact Pitch
- 0.079 inch
- Uzunluk
- 47.79mm
- Mixed Contacts
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Yayın Yılı
- 2000
- Montaj
- Through Hole
- Plating Thickness
- 30μin
- Gender
- Male
- Material Flammability Rating
- UL94 V-0
- Number Of Pcb Rows
- 2
- Parça Durumu
- Active
- Pitch Mating
- 0.079 2.00mm
- Mil Conformance
- NO
- Özellikler
- Keying Slot
- Fastening Type
- Latch Lock/Eject Hooks
- Number Of Conductors
- ONE
- Contact Lengthmating
- 0.120 3.05mm
- Number Of Positions Loaded
- All
- Montaj Tipi
- Through Hole
- JESD-609 Kodu
- e3
- Contact Type
- Male Pin
- Ul Flammability Code
- 94V-0
- Body Breadth
- 0.3 inch
- Contact Length Post
- 0.114 2.90mm
- Max Current Rating
- 3A
- Yükseklik
- 12.19mm
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Ambalaj
- Tube
- Contact Finish Post
- Tin
- Din Conformance
- NO
- Orientation
- Straight
- Pcb Contact Pattern
- RECTANGULAR
- Shrouding
- Shrouded - 4 Wall
- Iec Conformance
- NO
