Volume pricing
- 1+ pcs$8.57
- 10+ pcs$8.08
- 100+ pcs$7.63
- 500+ pcs$7.20
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Insulation Color
- Black
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Mounting Option2
- LOCKING
- Contact Finish Post
- Tin
- Ambalaj
- Tube
- Din Conformance
- NO
- Pcb Contact Pattern
- RECTANGULAR
- Orientation
- Straight
- Shrouding
- Shrouded - 4 Wall
- Board Mounting Option
- LOCKPIN
- Style
- Board to Cable/Wire
- Polarization Key
- CTR W/GUIDE SLOTS
- Mounting Option1
- LATCH & EJECT
- Contact Finish Mating
- Gold
- Iec Conformance
- NO
- Contact Shape
- Square
- Current Rating Amps
- 3A
- Sıra Sayısı
- 2
- Filter Feature
- NO
- Çalışma Sıcaklığı
- -55°C~125°C
- Pozisyon Sayısı
- 16
- Connector Type
- Header
- Contact Materials
- Phosphor Bronze
- Depth
- 7.62mm
- Terminal
- Solder
- Radyasyon Dayanımı
- No
- Row Spacing Mating
- 0.079 (2.00mm)
- Housing Material
- Polymer
- Pcb Contact Row Spacing
- 5.3086 mm
- Option
- GENERAL PURPOSE
- Additional Feature
- LATCHED
- Reliability
- COMMERCIAL
- Reference Standard
- UL
- Insulation Height
- 0.370 9.40mm
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 3 Weeks
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Seri
- EHT
- Mixed Contacts
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
