Volume pricing
- 1+ pcs$6.45
- 10+ pcs$6.09
- 100+ pcs$5.74
- 500+ pcs$5.42
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Style
- Board to Cable/Wire
- Polarization Key
- POLARIZED HOUSING
- Mounting Option1
- LATCH & EJECT
- Contact Finish Mating
- Gold
- Iec Conformance
- NO
- Shrouding
- Shrouded - 4 Wall
- Pcb Contact Pattern
- RECTANGULAR
- Orientation
- Straight
- Din Conformance
- NO
- Contact Finish Post
- Tin
- Ambalaj
- Tube
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Insulation Color
- Black
- Contact Length Post
- 0.114 2.90mm
- Max Current Rating
- 3A
- Insulation Height
- 0.370 9.40mm
- Reliability
- COMMERCIAL
- Reference Standard
- UL
- Option
- GENERAL PURPOSE
- Contact Materials
- Phosphor Bronze
- Connector Type
- Header
- Depth
- 7.62mm
- Terminal
- Solder
- Housing Material
- Polymer
- Row Spacing Mating
- 0.079 (2.00mm)
- Radyasyon Dayanımı
- No
- Pozisyon Sayısı
- 16
- Filter Feature
- NO
- Sıra Sayısı
- 2
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Shape
- Square
- Material Flammability Rating
- UL94 V-0
- Gender
- Male
- Plating Thickness
- 10μin
- Yayın Yılı
- 2015
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz Kodu
- yes
- Mixed Contacts
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 29.79mm
