Volume pricing
- 1+ pcs$8.23
- 10+ pcs$7.77
- 100+ pcs$7.33
- 500+ pcs$6.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Din Conformance
- NO
- Yayın Yılı
- 2003
- Contact Materials
- Phosphor Bronze
- Akım Değeri
- 1.75A
- Reach Svhc
- No SVHC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- JESD-609 Kodu
- e3
- RoHS Durumu
- ROHS3 Compliant
- Depth
- 6.67mm
- Çalışma Sıcaklığı
- -55°C~125°C
- Mixed Contacts
- NO
- Overall Contact Length
- 0.350 8.89mm
- Kurşunsuz Kodu
- yes
- Montaj
- Through Hole
- Filter Feature
- NO
- Additional Feature
- POLARIZED
- Contact Finish Post
- Tin
- Contact Shape
- Square
- Fastening Type
- Latch Lock/Eject Hooks
- Contact Finish Mating
- Gold
- Uzunluk
- 46.23mm
- Row Spacing Mating
- 0.050 (1.27mm)
- Polarization Key
- POLARIZED HOUSING
- Mil Conformance
- NO
- Iec Conformance
- NO
- Orientation
- Straight
- Seri
- EHF
- Housing Material
- Polymer
- Ambalaj
- Tube
- Number Of Conductors
- ONE
- Terminal
- Solder
- Contact Length Post
- 0.107 2.71mm
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Pitch Mating
- 0.050 1.27mm
- Reliability
- COMMERCIAL
- Mating Contact Pitch
- 0.05 inch
- Contact Type
- Male Pin
- Option
- GENERAL PURPOSE
- Pozisyon Sayısı
- 50
- Plating Thickness
- 10μin
