Volume pricing
- 1+ pcs$4.24
- 10+ pcs$4.00
- 100+ pcs$3.78
- 500+ pcs$3.56
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz Kodu
- yes
- Pozisyon Sayısı
- 20
- Contact Type
- Male Pin
- Option
- GENERAL PURPOSE
- Mixed Contacts
- NO
- Pitch Mating
- 0.050 1.27mm
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Terminal
- Solder
- Çalışma Sıcaklığı
- -55°C~125°C
- Depth
- 6.67mm
- RoHS Durumu
- ROHS3 Compliant
- JESD-609 Kodu
- e3
- Ambalaj
- Tube
- Housing Material
- Polymer
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Phosphor Bronze
- Seri
- EHF
- Din Conformance
- NO
- Mil Conformance
- NO
- Orientation
- Straight
- Yayın Yılı
- 2016
- Iec Conformance
- NO
- Parça Durumu
- Active
- Row Spacing Mating
- 0.050 (1.27mm)
- Uzunluk
- 27.18mm
- Contact Finish Mating
- Gold
- Sıra Sayısı
- 2
- Montaj Tipi
- Surface Mount
- Fastening Type
- Latch Lock/Eject Hooks
- Insulation Height
- 0.325 8.25mm
- Style
- Board to Cable/Wire
- Connector Type
- Header
- Number Of Positions Loaded
- All
- Contact Shape
- Square
- Shrouding
- Shrouded - 4 Wall
- Max Current Rating
- 1.75A
- Özellikler
- Board Lock, Keying Slot
- Insulation Materials
- Liquid Crystal Polymer (LCP), Glass Filled
- Contact Finish Post
- Tin
- Gender
- Male
