CLT-110-02-G-D-BE-A-K-TR

Specifications

Reliability

COMMERCIAL

Nem Hassasiyeti (MSL)

1 (Unlimited)

Kurşunsuz Kodu

yes

Din Conformance

NO

Board Mounting Option

POSITIONING PIN

Özellikler

Board Guide, Pick and Place

Montaj Tipi

Surface Mount

Insulation Color

Black

Insertion Forcemax

.5004 N

Insulation Height

0.083 2.10mm

Number Of Positions Loaded

All

JESD-609 Kodu

e4

ECCN Kodu

EAR99

Pitch Mating

0.079 2.00mm

Max Current Rating

3.3A

Çalışma Sıcaklığı

-55°C~125°C

Contact Shape

Square

Option

GENERAL PURPOSE

Number Of Pcb Rows

2

Pcb Contact Pattern

RECTANGULAR

Contact Finish Thickness Mating

10.0μin 0.25μm

Reference Standard

UL

Ambalaj

Tape & Reel (TR)

Filter Feature

NO

Contact Finish Mating

Gold

Contact Finish Thickness Post

3.00μin 0.076μm

RoHS Durumu

ROHS3 Compliant

HTS Kodu

8536.69.40.40

Connector Type

Receptacle, Bottom Entry

Contact Resistance

10mOhm

Durability

100 Cycles

Insulation Materials

Liquid Crystal Polymer (LCP)

Depth

5.16mm

Sıra Sayısı

2

Additional Feature

BOTTOM ENTRY, E.L.P., LOW PROFILE, TIGER CLAW CONTACT

Number Of Conductors

ONE

Fastening Type

Push-Pull

Total Number Of Contacts

20

Row Spacing Mating

0.079 (2.00mm)

Terminal

Solder
