Volume pricing
- 1+ pcs$1.42
- 10+ pcs$1.34
- 100+ pcs$1.26
- 500+ pcs$1.19
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- Mixed Contacts
- NO
- Contact Finish Mating
- Gold
- Pcb Contact Pattern
- STAGGERED
- Ambalaj
- Tube
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Surface Mount
- Option
- GENERAL PURPOSE
- Contact Materials
- Phosphor Bronze
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Style
- Board to Board
- Contact Type
- Female Socket
- Depth
- 1.78mm
- Insulation Color
- Black
- HTS Kodu
- 8536.69.40.40
- Din Conformance
- NO
- Sıra Sayısı
- 1
- Çalışma Sıcaklığı
- -55°C~125°C
- Number Of Positions Loaded
- All
- Terminal
- Solder
- Number Of Conductors
- ONE
- Total Number Of Contacts
- 7
- Material Flammability Rating
- UL94 V-0
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Pozisyon Sayısı
- 7
- Filter Feature
- NO
- Mil Conformance
- NO
- Contact Finish Post
- Tin
- Nominal Gerilim
- 240VAC 330VDC
- Yayın Yılı
- 2011
- Mating Contact Pitch
- 0.05 inch
- Current Rating Amps
- 3.3A per Contact
- Fastening Type
- Push-Pull
- Kurşunsuz Kodu
- yes
- Orientation
- Straight
- Contact Resistance
- 10mOhm
- Radyasyon Dayanımı
- No
- Connector Type
- Receptacle
- Contact Shape
- Square
- Housing Material
- Polymer
