Volume pricing
- 1+ pcs$1.41
- 10+ pcs$1.33
- 100+ pcs$1.25
- 500+ pcs$1.18
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Flammability Rating
- UL94 V-0
- Orientation
- Straight
- Kurşunsuz Kodu
- yes
- Pitch Mating
- 0.100 2.54mm
- Pcb Contact Pattern
- RECTANGULAR
- Contact Type
- Female Socket
- Reference Standard
- UL, CSA
- Din Conformance
- NO
- Iec Conformance
- NO
- Rated Current Signal
- 1A
- Mil Conformance
- NO
- Connector Type
- Receptacle
- Parça Durumu
- Active
- Sıra Sayısı
- 1
- Contact Shape
- Square
- Contact Length Post
- 0.128 3.25mm
- Yayın Yılı
- 1999
- Ambalaj
- Bulk
- JESD-609 Kodu
- e3
- Akım Değeri
- 1A
- HTS Kodu
- 8536.69.40.40
- Insertion Forcemax
- 2.224 N
- Mixed Contacts
- NO
- Additional Feature
- LOW PROFILE
- Fastening Type
- Push-Pull
- Style
- Board to Board
- Contact Resistance
- 10mOhm
- Lead Pitch
- 2.54mm
- Nominal Gerilim
- 333V
- Option
- GENERAL PURPOSE
- Ul Flammability Code
- 94V-0
- Housing Color
- Black
- RoHS Durumu
- ROHS3 Compliant
- Depth
- 3.05mm
- Insulation Materials
- Polybutylene Terephthalate (PBT)
- Seri
- CES
- Insulation Height
- 0.200 5.08mm
- Number Of Pcb Rows
- 1
- Montaj Tipi
- Through Hole
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
