Specifications
- ECCN Kodu
- EAR99
- Fastening Type
- Push-Pull
- Mounting Option1
- LOCKING
- Shrouding
- Unshrouded
- Terminal Adımı
- 1mm
- Kurşunsuz Kodu
- yes
- Insulation Color
- Black
- Seri
- BKT
- Number Of Positions Loaded
- All
- Fabrika Tedarik Süresi
- 3 Weeks
- Row Spacing Mating
- 0.100 (2.54mm)
- Pitch Mating
- 0.039 1.00mm
- Polarization Key
- POLARIZED HOUSING
- JESD-609 Kodu
- e3
- Contact Lengthmating
- 0.065 1.65mm
- Insulation Height
- 0.098 2.50mm
- Pcb Contact Pattern
- STAGGERED
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Contact Finish Post
- Tin
- Mating Contact Pitch
- 0.019 inch
- Yayın Yılı
- 2015
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Number Of Pcb Rows
- 2
- Connector Type
- Header
- Number Of Conductors
- ONE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Type
- Male Pin
- Iec Conformance
- NO
- Contact Shape
- Square
- Contact Finish Mating
- Gold
- Parça Durumu
- Active
- HTS Kodu
- 8536.69.40.40
- Pozisyon Sayısı
- 21
- Body Length Or Diameter
- 0.443 inch
- Reference Standard
- UL
- Montaj Tipi
- Surface Mount
- Contact Materials
- Phosphor Bronze
- Plating Thickness
- 10μin
- Ambalaj
- Tube
- Mil Conformance
- NO
