Volume pricing
- 1+ pcs$3.74
- 10+ pcs$3.53
- 100+ pcs$3.33
- 500+ pcs$3.14
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- JESD-609 Kodu
- e3
- Style
- Board to Board
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Reference Standard
- UL, CSA
- ECCN Kodu
- EAR99
- Number Of Positions Loaded
- 15
- Connector Type
- Receptacle
- Withdrawl Forcemin
- .834 N
- Gender
- Female
- Contact Finish Mating
- Gold
- RoHS Durumu
- ROHS3 Compliant
- Pitch Mating
- 0.100 2.54mm
- Contact Shape
- Square
- Additional Feature
- 4TH PIN POLARIZED
- Pozisyon Sayısı
- 16
- Pcb Contact Pattern
- STAGGERED
- Seri
- Tiger Claw™ BCS
- Insulation Resistance
- 5000000000Ohm
- Insulation Materials
- Liquid Crystal Polymer (LCP), Glass Filled
- Contact Finish Post
- Tin
- Nominal Gerilim
- 475VAC
- Insulation Height
- 0.110 2.79mm
- Dielectric Withstanding Voltage
- 375VAC V
- Çalışma Sıcaklığı
- -55°C~125°C
- Pcb Contact Row Spacing
- 7.874 mm
- Parça Durumu
- Active
- Terminal Adımı
- 2.54mm
- Sıra Sayısı
- 1
- Insulation Color
- Black
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2015
- Contact Type
- Female Socket
- Montaj
- Through Hole
- Reliability
- COMMERCIAL
- Polarization Key
- POLAR PIN POSITION
- Montaj Tipi
- Through Hole, Right Angle
- Current Rating Amps
- 4.6A per Contact
- Ambalaj
- Tube
- Body Depth
- 0.32 inch
- Contact Length Post
- 0.125 3.18mm
