SCS308AHGC9

Specifications

Nem Hassasiyeti (MSL)

1 (Unlimited)

Configuration

SINGLE

Operating Temperature Junction

175°C Max

Additional Feature

PD-CASE

Rep Pk Reverse Voltagemax

650V

Speed

No Recovery Time > 500mA (Io)

Case Connection

CATHODE

Voltage Forward Vf Max If

1.5V @ 8A

Tepe Reflow Sıcaklığı (°C)

NOT SPECIFIED

RoHS Durumu

RoHS Compliant

Current Reverse Leakage Vr

40μA @ 650V

Montaj Tipi

Through Hole

Tepe Reflow Süresi (maks. sn)

NOT SPECIFIED

Capacitance Vr F

400pF @ 1V 1MHz

Current Average Rectified Io

8A DC

Jedec95 Code

TO-220AC

Diode Type

Silicon Carbide Schottky

Nonrep Pk Forward Currentmax

57A

Reverse Currentmax

40μA

ECCN Kodu

EAR99

Jesd30 Code

R-PSFM-T2

Fabrika Tedarik Süresi

12 Weeks

Applications

GENERAL PURPOSE

Output Currentmax

8A

Number Of Elements

1

Power Dissipation Max

57W

Parça Durumu

Active

REACH Uyumluluk Kodu

compliant

Voltage Dc Reverse Vr Max

650V

Terminal Pozisyonu

SINGLE

Reverse Recovery Time

0ns

Terminal Sayısı

2

Kılıf / Paket

TO-220-2

Number Of Phases

1

Operating Temperature Max

175°C

Yüzey Montaj

NO
