Specifications
- Terminal Pozisyonu
- SINGLE
- Terminal Sayısı
- 3
- Kılıf / Paket
- TO-247-3
- Number Of Phases
- 1
- Operating Temperature Max
- 175°C
- Yüzey Montaj
- NO
- Jesd30 Code
- R-PSFM-T3
- Fabrika Tedarik Süresi
- 12 Weeks
- Applications
- GENERAL PURPOSE
- Output Currentmax
- 10A
- Number Of Elements
- 2
- Power Dissipation Max
- 280W
- Diode Configuration
- 1 Pair Common Cathode
- Parça Durumu
- Active
- Voltage Dc Reverse Vr Max
- 650V
- REACH Uyumluluk Kodu
- not_compliant
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz Kodu
- yes
- Current Reverse Leakage Vr
- 200μA @ 600V
- Yayın Yılı
- 2011
- Forward Current
- 20A
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Montaj Tipi
- Through Hole
- Ambalaj
- Tube
- Current Average Rectified Io
- 10A DC
- Diode Type
- Silicon Carbide Schottky
- Reverse Currentmax
- 200μA
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- Automotive, AEC-Q101
- HTS Kodu
- 8541.10.00.80
- Operating Temperature Junction
- 175°C Max
- Additional Feature
- PD-CASE
- Rep Pk Reverse Voltagemax
- 1200V
- Speed
- No Recovery Time > 500mA (Io)
- Voltage Forward Vf Max If
- 1.55V @ 10A
