Specifications
- Onstate Collector Currentnom
- 30mA
- Max Collector Current
- 30mA
- Pin Sayısı
- 4
- Fall Time Typ
- 10 μs
- Fonksiyon Sayısı
- 1
- Currentcollector Ic Max
- 30mA
- Yayın Yılı
- 2006
- Contact Plating
- Copper, Silver, Tin
- Forward Currentmax
- 0.035A
- Gap Size
- 5mm
- Kurşunsuz
- Lead Free
- RoHS Durumu
- ROHS3 Compliant
- Tip
- Unamplified
- Ambalaj
- Bulk
- Parça Durumu
- Not For New Designs
- Slot Widthnom
- 5mm
- Algılama Mesafesi
- 0.197 (5mm)
- Current Dc Forward If Max
- 50mA
- Sensing Method
- Through-Beam
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Output Configuration
- Phototransistor
- Kılıf / Paket
- PCB Mount
- Collector Emitter Voltage Vceo
- 30V
- Çalışma Sıcaklığı
- -25°C~85°C
- Power Dissipation
- 70mW
- Collectoremitter Breakdown Voltage
- 30V
- Rise Time
- 10μs
- Montaj
- Through Hole
- Montaj Tipi
- Through Hole
- Dark Currentmax
- 500nA
