Specifications
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz
- Lead Free
- Gap Size
- 5mm
- Yükseklik
- 10mm
- Uzunluk
- 13.8mm
- Contact Plating
- Copper, Silver, Tin
- Yayın Yılı
- 2006
- Fall Time Typ
- 10 μs
- Fonksiyon Sayısı
- 1
- Kurşunsuz Kodu
- yes
- Pin Sayısı
- 4
- Max Collector Current
- 30mA
- Fabrika Tedarik Süresi
- 13 Weeks
- Dark Currentmax
- 500nA
- Radyasyon Dayanımı
- No
- Voltage Rated Dc
- 1.3V
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Rise Time
- 10μs
- Power Dissipation
- 80mW
- Collectoremitter Breakdown Voltage
- 30V
- Number Of Channels
- 1
- Çalışma Sıcaklığı
- -25°C~85°C
- Collector Emitter Voltage Vceo
- 30V
- JESD-609 Kodu
- e1
- Forward Current
- 50mA
- Kılıf / Paket
- PCB Mount
- Output Configuration
- Phototransistor
- Reach Svhc
- No SVHC
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Sensing Method
- Through-Beam
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Current Dc Forward If Max
- 50mA
- Slot Widthnom
- 5mm
- Algılama Mesafesi
- 0.197 (5mm)
- Ambalaj
- Tube
- Parça Durumu
- Not For New Designs
- Forward Voltage
- 1.3V
- Tip
- Unamplified
- Genişlik
- 6mm
