Specifications
- Contact Plating
- Copper, Silver, Tin
- Yayın Yılı
- 2005
- Pin Sayısı
- 4
- Kurşunsuz Kodu
- yes
- Fonksiyon Sayısı
- 1
- Fall Time Typ
- 10 μs
- Fabrika Tedarik Süresi
- 12 Weeks
- Onstate Collector Currentnom
- 1.8mA
- Max Collector Current
- 30mA
- Kurşunsuz
- Lead Free
- RoHS Durumu
- ROHS3 Compliant
- Gap Size
- 1.2mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Output Configuration
- Phototransistor
- Kılıf / Paket
- Slotted Module
- Forward Current
- 50mA
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Slot Widthnom
- 1.2mm
- Algılama Mesafesi
- 0.047 (1.2mm)
- Current Dc Forward If Max
- 50mA
- Tip
- Unamplified
- Dark Currentmax
- 500nA
- Montaj
- Through Hole
- Montaj Tipi
- Through Hole
- Collectoremitter Breakdown Voltage
- 30V
- Power Dissipation
- 80mW
- Rise Time
- 10μs
- JESD-609 Kodu
- e1
- Collector Emitter Voltage Vceo
- 30V
- Çalışma Sıcaklığı
- -25°C~85°C
