Specifications
- JESD-609 Kodu
- e1
- Bus Compatibility
- PCI
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz Kodu
- yes
- Contact Plating
- Copper, Silver, Tin
- Besleme Gerilimi
- 3.3V
- ECCN Kodu
- 3A001.A.3
- Terminal Formu
- BALL
- Pin Sayısı
- 288
- Function
- Controller
- Terminal Adımı
- 0.8mm
- Power Supplies
- 1.51.83.33.3/5V
- Kılıf / Paket
- 288-LFBGA
- External Data Bus Width
- 32
- Terminal Sayısı
- 288
- Tedarikçi Cihaz Paketi
- 288-BGA Microstar (16x16)
- Terminal Pozisyonu
- BOTTOM
- Temperature Grade
- COMMERCIAL
- Operating Temperature Max
- 70°C
- Protocol
- PCI CardBus
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Data Transfer Ratemax
- 132 MBps
- Uzunluk
- 16mm
- Interface
- PCI
- Clock Frequency
- 48MHz
- Standards
- IEEE 1394-1995, 1394a-2000, OHCI, Firewire™, i.Link™
- Kurşunsuz
- Contains Lead
- Address Bus Width
- 32
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Ambalaj
- Tray
- Parça Durumu
- Obsolete
- Temel Parça No
- PCI7621
- Radyasyon Dayanımı
- No
- Besleme Gerilimi
- 3.3V 5V
- Maks. Oturma Yüksekliği
- 1.4mm
- Montaj
- Surface Mount
- HTS Kodu
- 8542.31.00.01
- Genişlik
- 16mm
- Tepe Reflow Sıcaklığı (°C)
- 260
- Weight
- 617.509313mg
