Specifications
- RoHS Durumu
- ROHS3 Compliant
- Motor Type Ac Dc
- Brushless DC (BLDC)
- Besleme Gerilimi
- 6V~15V
- Terminal Kaplaması
- Tin/Bismuth (Sn/Bi)
- Montaj Tipi
- Surface Mount
- Kılıf / Paket
- 36-LSOP (0.220, 5.60mm Width) Exposed Pad
- Analog Ic Other Type
- AC MOTOR CONTROLLER
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Lifecycle Status
- LIFETIME (Last Updated: 3 days ago)
- Output Voltage
- 17V
- Yayın Yılı
- 2015
- Supply Voltagemin Vsup
- 6V
- HTS Kodu
- 8542.39.00.01
- Parça Durumu
- Obsolete
- Besleme Gerilimi
- 12V
- Nominal Supply Current
- 3.6mA
- Maks. Oturma Yüksekliği
- 1.7mm
- Output Configuration
- Half Bridge (3)
- Tedarikçi Cihaz Paketi
- 36-SSOPJ
- Operating Supply Voltage
- 15V
- Terminal Formu
- GULL WING
- Halogen Free
- Halogen Free
- Function
- Driver - Fully Integrated, Control and Power Stage
- Terminal Adımı
- 0.8mm
- Kurşunsuz
- Lead Free
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Genişlik
- 5.6mm
- Çıkış Akımı
- 1.2A
- Power Supplies
- 12V
- Kurşunsuz Kodu
- yes
- Terminal Sayısı
- 36
- Uzunluk
- 15mm
- JESD-609 Kodu
- e6
- Montaj
- Surface Mount
- Voltage Load
- 6V~15V
- Qualification Status
- Not Qualified
- Logic Function
- AND
- Pin Sayısı
- 36
- Çalışma Sıcaklığı
- -40°C~95°C TA
