Specifications
- Analog Ic Other Type
- DISK DRIVE MOTOR CONTROLLER
- Terminal Formu
- GULL WING
- Logic Function
- AND
- Tedarikçi Cihaz Paketi
- 44-SSOPJ
- Genişlik
- 5.6mm
- JESD-609 Kodu
- e6
- Function
- Driver - Fully Integrated, Control and Power Stage
- Qualification Status
- Not Qualified
- Interface
- Parallel, PWM
- HTS Kodu
- 8542.39.00.01
- Supply Voltagemin Vsup
- 4V
- Jesd30 Code
- R-PDSO-G44
- Power Supplies
- 512V
- Parça Durumu
- Obsolete
- Motor Type Ac Dc
- Brushless DC (BLDC), Brushed DC
- Kılıf / Paket
- 44-LSSOP (0.220, 5.60mm Width) Exposed Pad
- Lifecycle Status
- OBSOLETE (Last Updated: 3 days ago)
- Besleme Gerilimi
- 5V
- Çalışma Sıcaklığı
- -20°C~75°C TA
- Besleme Gerilimi
- 4V~6V
- Output Configuration
- Half Bridge (8)
- Kurşunsuz
- Lead Free
- Çıkış Akımı
- 200mA
- Uzunluk
- 15mm
- Ambalaj
- Tube
- Terminal Adımı
- 0.65mm
- RoHS Durumu
- ROHS3 Compliant
- Montaj Tipi
- Surface Mount
- Kurşunsuz Kodu
- yes
- Terminal Kaplaması
- Tin/Bismuth (Sn/Bi)
- Terminal Pozisyonu
- DUAL
- Maks. Oturma Yüksekliği
- 1.7mm
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Yayın Yılı
- 2014
- Voltage Load
- 8V~16V 8V~28V
- Montaj
- Surface Mount
- Supply Voltagemax Vsup
- 6V
- Terminal Sayısı
- 44
- Supply Currentmax Isup
- 25mA
- Applications
- General Purpose
