Specifications
- Parça Durumu
- Obsolete
- Nominal Supply Current
- 3.35mA
- Output Current
- 20A
- Montaj
- PCB, Through Hole
- Akım
- 20A
- Jesd30 Code
- R-XZFM-T18
- Terminal Sayısı
- 18
- Collector Emitter Voltage Vceo
- 600V
- Min. Çalışma Sıcaklığı
- -40°C
- Uzunluk
- 77.978mm
- Operating Supply Voltage
- 15V
- Min Supply Voltage
- 12V
- Output Voltage
- 450V
- Paket
- Tube
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Collectoremitter Breakdown Voltage
- 600V
- Rms Current Irms
- 20A
- Frekans
- 20kHz
- Radyasyon Dayanımı
- No
- Number Of Outputs
- 3
- Terminal Adımı
- 2.54mm
- Yayın Yılı
- 2005
- Ürün Durumu
- Obsolete
- Ambalaj
- Box
- Kurşunsuz
- Lead Free
- RoHS Durumu
- ROHS3 Compliant
- Tip
- IGBT
- Kılıf / Paket
- 22-PowerSIP Module, 18 Leads, Formed Leads
- Genişlik
- 5.9944mm
- Power Dissipation
- 4.5W
- Gerilim
- 600V
- Reach Svhc
- No SVHC
- Terminal Pozisyonu
- ZIG-ZAG
- Voltage Isolation
- 2000Vrms
- Input Bias Current
- 200μA
- Quiescent Current
- 165μA
- Besleme Gerilimi
- 15V
- Max Supply Voltage
- 20V
- Fonksiyon Sayısı
- 1
- Configuration
- 3 Phase
