Specifications
- Output Configuration
- Half Bridge (3)
- Besleme Gerilimi
- 15V
- Output Current
- 1mA
- Pin Sayısı
- 22
- Kılıf / Paket
- 22-DIP Module
- Ambalaj
- Tube
- Number Of Outputs
- 3
- Seri
- Motion-SPM®
- Power Supplies
- 15V
- Analog Ic Other Type
- ANALOG CIRCUIT
- Terminal Sayısı
- 22
- Besleme Gerilimi
- 13.5V~16.5V
- Radyasyon Dayanımı
- No
- Logic Function
- AND
- HTS Kodu
- 8541.29.00.95
- Montaj
- Through Hole
- Weight
- 11.079g
- RoHS Durumu
- Non-RoHS Compliant
- Min Breakdown Voltage
- 40V
- Output Voltage
- 4.5V
- Collector Emitter Voltage Vceo
- 40V
- Montaj Tipi
- Through Hole
- Yayın Yılı
- 2014
- Max Power Dissipation
- 28W
- Function
- Driver - Fully Integrated, Control and Power Stage
- Supply Voltagemax Vsup
- 16.5V
- Genişlik
- 19.3mm
- Motor Type Ac Dc
- Brushless DC (BLDC)
- Kurşunsuz Kodu
- yes
- Yükseklik
- 4.6mm
- Applications
- General Purpose
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Voltage Load
- 20V
- Uzunluk
- 35.3mm
- Max Collector Current
- 57A
- ECCN Kodu
- EAR99
- Max Current Rating
- 57A
- Terminal Kaplaması
- Tin (Sn)
- Interface
- Parallel
