Specifications
- Parça Durumu
- Active
- Data Rate
- 10Mbps
- Ambalaj
- Tube
- Besleme Gerilimi
- 4.5V~5.5V
- Optoelectronic Device Type
- LOGIC IC OUTPUT OPTOCOUPLER
- Fabrika Tedarik Süresi
- 16 Weeks
- Number Of Elements
- 1
- Çalışma Sıcaklığı
- -40°C~85°C
- Onstate Currentmax
- 0.025A
- Inputs Side1side2
- 1/0
- Giriş Tipi
- DC
- Number Of Channels
- 1
- Direction
- Unidirectional
- Voltage Forward Vf Typ
- 1.65V
- Kurşunsuz Kodu
- yes
- Propagation Delay
- 75 ns
- Output Current Per Channel
- 25mA
- Additional Feature
- UL RECOGNIZED
- Çıkış Tipi
- Open Collector
- Fall Time Typ
- 10 ns
- Common Mode Transient Immunity Min
- 15kV/μs
- JESD-609 Kodu
- e4
- Max Power Dissipation
- 40mW
- Pin Sayısı
- 8
- Montaj
- Surface Mount
- Configuration
- SINGLE
- Rise Fall Time Typ
- 20ns 10ns
- Propagation Delay Tplh Tphl Max
- 75ns, 75ns
- Current Dc Forward If Max
- 30mA
- Montaj Tipi
- Surface Mount
- Terminal Kaplaması
- Nickel/Palladium/Gold (Ni/Pd/Au)
- Forward Currentmax
- 0.03A
- Kılıf / Paket
- 8-SMD, Gull Wing
- RoHS Durumu
- ROHS3 Compliant
- Seri
- NEPOC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Isolation
- 5000Vrms
- Radyasyon Dayanımı
- No
