116-83-310-41-002101

Specifications

Tip

DIP, 0.3 (7.62mm) Row Spacing

Contact Resistance

10mOhm

Flammability Rating

UL94 V-0

Contact Material Post

Brass

Contact Material Mating

Beryllium Copper

Nem Hassasiyeti (MSL)

1 (Unlimited)

Lead Length

3.175mm

Akım Değeri

1A

Fabrika Tedarik Süresi

10 Weeks

ECCN Kodu

EAR99

RoHS Durumu

ROHS3 Compliant

Termination Post Length

0.125 3.18mm

Contact Finish Thickness Mating

29.5μin 0.75μm

Number Of Positions Or Pins Grid

10 (2 x 5)

Çalışma Sıcaklığı

-55°C~125°C

Contact Finish Mating

Gold

Housing Material

Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled

Row Spacing

7.62 mm

Number Of Contacts

10

HTS Kodu

8536.69.40.40

Kurşunsuz Kodu

yes

Parça Durumu

Active

Voltage Rated Dc

150V

Pitch Post

0.100 2.54mm

Material Flammability Rating

UL94 V-0

Montaj

Through Hole

Montaj Tipi

Through Hole

Özellikler

Elevated, Open Frame

Contact Materials

Copper

Insulation Resistance

10GOhm

Uzunluk

12.6mm

JESD-609 Kodu

e3

Orientation

Straight

Terminal

Solder

Sıra Sayısı

2

Voltage Rated Ac

100V

Additional Feature

94V-0

Depth

7.6mm

Ambalaj

Bulk

Insulation Materials

Polychlorinated
