Specifications
- Material Insulation
- Polyamide (PA), Nylon
- Wire Gauge Or Range Awg
- 6-14 AWG
- Parça Durumu
- Obsolete
- Disconnect Type
- Fuse, Lever
- Pozisyon Sayısı
- 2
- Weight
- 226.796185g
- Onay Kuruluşu
- CSA, UL
- Currentul
- 60A
- Number Of Levels
- 1
- Nominal Gerilim
- 600V
- Genişlik
- 40mm
- Uzunluk
- 118mm
- Connector Type
- Screw
- Wire Gauge Max
- 14 AWG
- Terminal Width
- 40.0mm
- Gerilim
- 600V
- Wire Gauge Min
- 6 AWG
- Number Of Poles
- 2
- Akım Değeri
- 60A
- Akım
- 60A
- Yayın Yılı
- 2011
- Tip
- Disconnect
- Stripping Length
- 20mm
- Currentiec
- 60A
- Seri
- CLIPLINE UK
- RoHS Durumu
- RoHS Compliant
- Terminal Stili
- Screw
- Wire Gauge Or Range Mm
- 2.5-50mm2
- Material
- Polyamide
- Montaj
- DIN Rail
- Fuse Type
- 27mm x 60mm
- Voltageiec
- 600V
- Flammability Rating
- UL94 V-0
- Renk
- Black
- Fabrika Tedarik Süresi
- 5 Weeks
- Terminal
- Screw
- Material Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
