Volume pricing
- 1+ pcs$3.92
- 10+ pcs$3.70
- 100+ pcs$3.49
- 500+ pcs$3.29
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Min
- 12 AWG
- Gerilim
- 300V
- ECCN Kodu
- EAR99
- Akım Değeri
- 20A
- Genişlik
- 5.2mm
- Wire Gauge Max
- 26 AWG
- Uzunluk
- 102mm
- Safety Approval
- UL; CSA
- Nominal Gerilim
- 500V
- Yükseklik
- 58mm
- Number Of Levels
- 3; 1 Grounded
- Pozisyon Sayısı
- 6
- Sıra Sayısı
- 3
- Material Insulation
- Polyamide (PA), Nylon
- Wire Gauge Or Range Awg
- 12-26 AWG
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Number Of Decks
- 3
- Wirecable Gauge
- 12 AWG
- Material Flammability Rating
- UL94 V-0
- Additional Feature
- STANDARD: UL 94V-0, PA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Renk
- Gray
- Fabrika Tedarik Süresi
- 7 Weeks
- Terminal
- Push-In
- Voltageiec
- 500V
- Flammability Rating
- UL94 V-0
- RoHS Durumu
- RoHS Compliant
- Terminal Stili
- Push In, Spring
- Wire Gauge Or Range Mm
- 0.14-4mm2
- Tip
- Feed Through
- Stripping Length
- 10mm
- Number Of Ways
- 6
- Seri
- CLIPLINE PT
- Akım
- 20A
- Wire Cross Section
- 4 mm2
- Yayın Yılı
- 2010
