Volume pricing
- 1+ pcs$9.54
- 10+ pcs$9.00
- 100+ pcs$8.49
- 500+ pcs$8.01
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yükseklik
- 65.5mm
- Number Of Levels
- 3; Connected
- Safety Approval
- UL; CSA
- Genişlik
- 5.2mm
- Uzunluk
- 102mm
- Connector Type
- Push-In
- Wire Gauge Max
- 26 AWG
- ECCN Kodu
- EAR99
- Akım Değeri
- 20A
- Wire Gauge Min
- 12 AWG
- Kurşunsuz Kodu
- yes
- Number Of Decks
- 3
- Material Insulation
- Polyamide (PA), Nylon
- Kurşunsuz
- Lead Free
- Wire Gauge Or Range Awg
- 12-26 AWG
- Parça Durumu
- Active
- Sıra Sayısı
- 3
- Onay Kuruluşu
- CB, CSA, UL, VDE
- Pozisyon Sayısı
- 6
- Housing Material
- Nylon
- Flammability Rating
- UL94 V-0
- Renk
- Green, Yellow
- Fabrika Tedarik Süresi
- 7 Weeks
- Additional Feature
- STANDARD: UL 94V-0, PA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Wirecable Gauge
- 12 AWG
- Material Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2010
- Wire Cross Section
- 4 mm2
- Number Of Ways
- 6
- Seri
- CLIPLINE PT
- Tip
- Ground, Earth
- Stripping Length
- 10mm
- Terminal Stili
- Push In, Spring
- Wire Gauge Or Range Mm
- 0.14-4mm2
- RoHS Durumu
- RoHS Compliant
