Volume pricing
- 1+ pcs$5.19
- 10+ pcs$4.89
- 100+ pcs$4.62
- 500+ pcs$4.35
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Max
- 26 AWG
- Kurşunsuz Kodu
- yes
- Pozisyon Sayısı
- 3
- Terminal Stili
- Push In
- Renk
- Gray
- Voltageiec
- 400V
- Yayın Yılı
- 2015
- Gerilim
- 300V
- Terminal Width
- 3.5mm
- Disconnect Type
- Switch, Knife
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 16-26 AWG
- RoHS Durumu
- RoHS Compliant
- Fabrika Tedarik Süresi
- 4 Weeks
- Seri
- CLIPLINE PT
- Tip
- Disconnect
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Number Of Levels
- 1
- Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım
- 10A
- Material Insulation
- Polyamide (PA), Nylon
- Stripping Length
- 8mm
- Parça Durumu
- Active
- Wire Gauge Min
- 16 AWG
