Volume pricing
- 1+ pcs$1.05
- 10+ pcs$0.99
- 100+ pcs$0.93
- 500+ pcs$0.88
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- HTS Kodu
- 8536.69.40.40
- Wire Gauge Min
- 16 AWG
- Parça Durumu
- Active
- REACH Uyumluluk Kodu
- unknown
- Stripping Length
- 8mm
- Number Of Decks
- 1
- Material Insulation
- Polyamide (PA), Nylon
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım
- 10A
- Number Of Levels
- 1
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Seri
- CLIPLINE PT
- Tip
- Disconnect
- Additional Feature
- STANDARD: UL 94V-0, PA
- Safety Approval
- CSA; CUL; EAC; UL
- Fabrika Tedarik Süresi
- 4 Weeks
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Awg
- 16-26 AWG
- Disconnect Type
- Switch, Knife
- Material Flammability Rating
- UL94 V-0
- Terminal Width
- 3.5mm
- Gerilim
- 300V
- Yayın Yılı
- 2015
- Number Of Ways
- 2
- Voltageiec
- 400V
- Renk
- Gray
- Terminal Stili
- Push In, Spring
- Pozisyon Sayısı
- 2
- Wire Gauge Max
- 26 AWG
- Sıra Sayısı
- 1
