Volume pricing
- 1+ pcs$5.25
- 10+ pcs$4.95
- 100+ pcs$4.67
- 500+ pcs$4.41
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2010
- Number Of Ways
- 4
- Voltageiec
- 800V
- Renk
- Gray
- Terminal Stili
- Push In, Spring
- Kurşunsuz Kodu
- yes
- Pozisyon Sayısı
- 4
- Wire Gauge Max
- 26 AWG
- Wirecable Gauge
- 12 AWG
- Akım Değeri
- 500mA
- Sıra Sayısı
- 1
- Montaj
- Through Hole
- ECCN Kodu
- EAR99
- Uzunluk
- 72mm
- Connector Type
- Push-In
- RoHS Durumu
- RoHS Compliant
- Weight
- 10.019997g
- Onay Kuruluşu
- CSA, UL
- Wire Gauge Or Range Awg
- 12-26 AWG
- Material Flammability Rating
- UL94 V-0
- Gerilim
- 300V
- Flammability Rating
- UL94 V-0
- Number Of Levels
- 1
- Genişlik
- 5.2mm
- Wire Gauge Or Range Mm
- 0.14-4mm2
- Seri
- CLIPLINE PT
- Tip
- Feed Through
- Safety Approval
- UL
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Gauge Min
- 12 AWG
- Parça Durumu
- Active
- Nominal Gerilim
- 800V
- Stripping Length
- 10mm
- Number Of Decks
- 1
- Currentiec
- 0.5A
- Özellikler
- Diode
- Material Insulation
- Polyamide (PA), Nylon
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım
- 20A
