Volume pricing
- 1+ pcs$1.39
- 10+ pcs$1.31
- 100+ pcs$1.24
- 500+ pcs$1.17
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Tip
- Ground, Earth
- Additional Feature
- STANDARD: UL 94V-0, PA
- Number Of Levels
- 1
- Number Of Ways
- 2
- Yükseklik
- 44mm
- Stripping Length
- 10mm
- Yayın Yılı
- 2010
- Wire Gauge Min
- 26 AWG
- Terminal Stili
- Push In, Spring
- Parça Durumu
- Active
- Genişlik
- 5.2mm
- ECCN Kodu
- EAR99
- Flammability Rating
- UL94 V-0
- Kurşunsuz
- Lead Free
- Renk
- Green, Yellow
- Material Insulation
- Polyamide (PA), Nylon
- Wire Gauge Or Range Awg
- 12-26 AWG
- Wire Gauge Or Range Mm
- 0.14-4mm2
- Number Of Decks
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Poles
- 2
- Seri
- CLIPLINE PT
- Sıra Sayısı
- 1
- HTS Kodu
- 8536.69.40.40
- RoHS Durumu
- RoHS Compliant
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Polyamide
- Safety Approval
- UL; CSA
- Wirecable Gauge
- 12 AWG
- Wire Gauge Max
- 26 AWG
- Fabrika Tedarik Süresi
- 7 Weeks
- Connector Type
- Push-In
- Kurşunsuz Kodu
- yes
- Onay Kuruluşu
- CB, CSA, UL, VDE
- Uzunluk
- 48.5mm
