Volume pricing
- 1+ pcs$0.29
- 10+ pcs$0.27
- 100+ pcs$0.26
- 500+ pcs$0.24
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Genişlik
- 5.2mm
- Terminal Stili
- Push In, Spring
- Wire Gauge Min
- 12 AWG
- Kurşunsuz
- Lead Free
- Flammability Rating
- UL94 V-0
- Material Insulation
- Polyamide (PA), Nylon
- Renk
- Gray
- ECCN Kodu
- EAR99
- Voltageiec
- 800V
- Wire Gauge Or Range Awg
- 12-26 AWG
- Wire Gauge Or Range Mm
- 0.14-4mm2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Nominal Gerilim
- 800V
- Number Of Decks
- 1
- Akım Değeri
- 24A
- Weight
- 6.39999g
- Tip
- Feed Through
- Max Current Rating
- 24A
- Reach Svhc
- Unknown
- Additional Feature
- STANDARD: UL 94V-0, PA
- Yükseklik
- 35.3mm
- Number Of Levels
- 1
- Number Of Ways
- 2
- Yayın Yılı
- 2010
- Stripping Length
- 10mm
- RoHS Durumu
- RoHS Compliant
- Material Flammability Rating
- UL94 V-0
- Montaj
- Through Hole
- Wirecable Gauge
- 12 AWG
- Housing Material
- Polyamide
- Safety Approval
- UL; CSA
- Fabrika Tedarik Süresi
- 7 Weeks
- Connector Type
- Push-In
- Kurşunsuz Kodu
- yes
- Onay Kuruluşu
- CB, CSA, UL, VDE
- Uzunluk
- 48.5mm
- Wire Gauge Max
- 26 AWG
- Pozisyon Sayısı
- 2
- Number Of Poles
- 2
