Volume pricing
- 1+ pcs$2.43
- 10+ pcs$2.29
- 100+ pcs$2.16
- 500+ pcs$2.04
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Flammability Rating
- UL94 V-0
- Montaj
- Through Hole
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Max
- 20 AWG
- Pozisyon Sayısı
- 3
- Fabrika Tedarik Süresi
- 11 Weeks
- Connector Type
- Push-In
- Uzunluk
- 88.9mm
- Housing Material
- Nylon
- Safety Approval
- BV; CB; CSA; CUL; GOST; GL; LR
- Wirecable Gauge
- 6 AWG
- Seri
- CLIPLINE PT
- Sıra Sayısı
- 1
- Akım
- 60A
- Gerilim
- 600V
- ECCN Kodu
- EAR99
- Voltageiec
- 1000V
- Flammability Rating
- UL94 V-0
- Material Insulation
- Polyamide (PA), Nylon
- Renk
- Gray
- Wire Gauge Min
- 6 AWG
- Terminal Stili
- Push In, Spring
- Parça Durumu
- Active
- Genişlik
- 10.2mm
- Number Of Decks
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Nominal Gerilim
- 1kV
- Wire Gauge Or Range Awg
- 6-20 AWG
- Wire Gauge Or Range Mm
- 0.5-16mm2
- Currentiec
- 57A
- Tip
- Feed Through
- Additional Feature
- STANDARD: UL 94V-0, PA, SAFETY APPROVAL: NK; UL; VDE
- Weight
- 38.399996g
- Akım Değeri
- 57A
- Stripping Length
- 18mm
- Yayın Yılı
- 2015
- Number Of Levels
- 1
- Number Of Ways
- 3
- Yükseklik
- 49.5mm
