Volume pricing
- 1+ pcs$2.64
- 10+ pcs$2.49
- 100+ pcs$2.35
- 500+ pcs$2.21
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Sıra Sayısı
- 3
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Min
- 16 AWG
- Terminal Stili
- IDC
- Parça Durumu
- Active
- Max Current Rating
- 17.5A
- Renk
- Blue
- Orientation
- Straight
- Contact Materials
- Metal
- Kurşunsuz
- Lead Free
- Seri
- CLIPLINE QTC
- Yükseklik
- 39.3mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- RoHS Compliant
- Voltageiec
- 800V
- Kurşunsuz Kodu
- yes
- Onay Kuruluşu
- CSA, UL, cULus
- Max Supply Voltage
- 800V
- Number Of Levels
- 1
- Housing Material
- Polyamide
- REACH Uyumluluk Kodu
- unknown
- Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 800V
- Wire Gauge Or Range Awg
- 16-24 AWG
- Akım Değeri
- 17.5A
- Wire Gauge Max
- 24 AWG
- Akım
- 10A
- Genişlik
- 5.2mm
- Yayın Yılı
- 2006
- Gerilim
- 600V
- Tip
- Feed Through
- Wire Gauge Or Range Mm
- 0.25-1.5mm2
- ECCN Kodu
- EAR99
- Wirecable Gauge
- 16 AWG
- Weight
- 11.939997g
- Uzunluk
- 76.4mm
- Depth
- 5.2mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Material Insulation
- Polyamide (PA), Nylon
