Volume pricing
- 1+ pcs$6.38
- 10+ pcs$6.02
- 100+ pcs$5.68
- 500+ pcs$5.36
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wirecable Gauge
- 24 AWG
- Connector Type
- Screw, Terminal Block
- Renk
- Black
- Tip
- Disconnect
- Material Flammability Rating
- UL94 V-0
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Max
- 28 AWG
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2006
- Uzunluk
- 59.5mm
- Number Of Poles
- 1
- Yükseklik
- 65.5mm
- Housing Material
- Polyamide
- Terminal Stili
- Screw
- Safety Approval
- UL; CSA
- Pozisyon Sayısı
- 2
- HTS Kodu
- 8536.69.40.40
- Weight
- 17.600008g
- Wire Gauge Or Range Awg
- 12-28 AWG
- Onay Kuruluşu
- CB, CSA, UL, VDE
- Seri
- CLIPLINE UK
- Fuse Type
- 5mm x 20mm, 5mm x 25mm
- Akım Değeri
- 6.3A
- Fabrika Tedarik Süresi
- 4 Weeks
- Material Insulation
- Polyamide (PA), Nylon
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Wire Gauge Min
- 12 AWG
- Lead Pitch
- 8.2mm
- ECCN Kodu
- EAR99
- Akım
- 10A
- Nominal Gerilim
- 400V
- Voltage Rated Ac
- 250V
- Currentiec
- 6.3A
- Reach Svhc
- No SVHC
- Gerilim
- 300V
- Kurşunsuz Kodu
- yes
- Genişlik
- 8.2mm
- Parça Durumu
- Active
- Stripping Length
- 9mm
