Volume pricing
- 1+ pcs$8.79
- 10+ pcs$8.30
- 100+ pcs$7.83
- 500+ pcs$7.38
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Max
- 28 AWG
- HTS Kodu
- 8536.69.40.40
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 46mm
- Kılıf / Paket
- Module
- Nominal Gerilim
- 400V
- Kurşunsuz Kodu
- yes
- Material Insulation
- Polyamide (PA), Nylon
- Seri
- CLIPLINE MTKD
- Özellikler
- Thermocouple, Nickel-Chrome/Constantan
- Yayın Yılı
- 2010
- Number Of Contacts
- 2
- Tip
- Feed Through
- Weight
- 16.400001g
- Fabrika Tedarik Süresi
- 4 Weeks
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Min
- 24 AWG
- Flammability Rating
- UL94 V-0
- Renk
- Gray
- Akım Değeri
- 1A
- ECCN Kodu
- EAR99
- Akım
- 10A
- Currentiec
- 1A
- Terminal Stili
- Screw
- RoHS Durumu
- RoHS Compliant
- Max Current Rating
- 10A
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Parça Durumu
- Active
- Gerilim
- 300V
- Wire Gauge Or Range Awg
- 12-28 AWG
- Kurşunsuz
- Lead Free
- Housing Material
- Polyamide
- Number Of Levels
- 1
- Genişlik
- 10.4mm
- Stripping Length
- 7mm
