Volume pricing
- 1+ pcs$8.39
- 10+ pcs$7.91
- 100+ pcs$7.46
- 500+ pcs$7.04
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Gerilim
- 300V
- Wire Gauge Or Range Awg
- 12-28 AWG
- Housing Material
- Polyamide
- Yükseklik
- 47.5mm
- Kurşunsuz
- Lead Free
- Genişlik
- 10.4mm
- Number Of Levels
- 1
- Pozisyon Sayısı
- 2
- Stripping Length
- 7mm
- Renk
- Gray
- Akım Değeri
- 10A
- Currentiec
- 1A
- Akım
- 10A
- ECCN Kodu
- EAR99
- Terminal Stili
- Screw
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Parça Durumu
- Active
- Voltageiec
- 400V
- Kurşunsuz Kodu
- yes
- Nominal Gerilim
- 400V
- Kılıf / Paket
- Module
- Material Insulation
- Polyamide (PA), Nylon
- Özellikler
- Thermocouple, Copper/Constantan
- Seri
- CLIPLINE MTKD
- Weight
- 16.400001g
- Tip
- Feed Through
- Fabrika Tedarik Süresi
- 4 Weeks
- Yayın Yılı
- 2010
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Min
- 12 AWG
- Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 28 AWG
- HTS Kodu
- 8536.69.40.40
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 46mm
