Volume pricing
- 1+ pcs$0.83
- 10+ pcs$0.79
- 100+ pcs$0.74
- 500+ pcs$0.70
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz Kodu
- yes
- Wire Gauge Max
- 24 AWG
- Max Current Rating
- 41A
- Uzunluk
- 44.4mm
- Flammability Rating
- UL94 V-0
- Akım
- 30A
- Seri
- CLIPLINE UW
- HTS Kodu
- 8536.69.40.40
- Panel Thickness
- 0.039 ~ 0.157 1.0 ~ 4.0mm
- Kurşunsuz
- Lead Free
- Genişlik
- 0.319 8.10mm
- Panel Mount Type
- 2 Piece
- Nominal Gerilim
- 500V
- Montaj
- Plug-In, Wall
- Gender
- Female
- Material
- Polyamide
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2012
- Terminal
- Screw
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 4 Weeks
- Gerilim
- 600V
- Front Panel Wire Connection
- Bolt/Screw Clamp - Wire Entry 90° to Panel
- Akım Değeri
- 41A
- ECCN Kodu
- EAR99
- Pozisyon Sayısı
- 2
- Ambalaj
- Bulk
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Number Of Levels
- 1
- Rear Panel Wire Connection
- Bolt/Screw Clamp - Wire Entry 90° to Panel
- Renk
- Gray
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- REACH Uyumluluk Kodu
- unknown
- Yükseklik
- 23.5mm
- Weight
- 10.399994g
- Wire Gauge
- 10-24 AWG
- Orientation
- Straight
- Wire Gauge Min
- 10 AWG
