Volume pricing
- 1+ pcs$2.15
- 10+ pcs$2.03
- 100+ pcs$1.91
- 500+ pcs$1.80
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Housing Material
- Polyamide
- Depth
- 5.2mm
- Wire Gauge Or Range Mm
- 0.25-1.5mm2
- Flammability Rating
- UL94 V-0
- Weight
- 1.149857kg
- Onay Kuruluşu
- CSA, UL, cULus
- Orientation
- Straight
- Seri
- CLIPLINE QTCU
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 7 Weeks
- Max Current Rating
- 17.5A
- Max Supply Voltage
- 800V
- Yükseklik
- 50.3mm
- Akım
- 10A
- Number Of Levels
- 1
- Tip
- Feed Through
- Number Of Ways
- 3
- Wire Cross Section
- 2.5 mm2
- Material Insulation
- Polyamide (PA), Nylon
- Safety Approval
- CSA; CUL; GL; GOST; UL
- Montaj
- Through Hole
- Renk
- Gray
- Wire Gauge Min
- 12 AWG
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Genişlik
- 5.2mm
- Material Flammability Rating
- UL94 V-0
- Voltageiec
- 800V
- Wirecable Gauge
- 16 AWG
- Terminal Stili
- IDC, Screw
- Wire Gauge Max
- 26 AWG
- Uzunluk
- 76.4mm
- Additional Feature
- PA, UL 94V-0
- REACH Uyumluluk Kodu
- unknown
- RoHS Durumu
- RoHS Compliant
- Sıra Sayısı
- 3
- Nominal Gerilim
- 800V
- Akım Değeri
- 17.5A
- Terminal
- Screw
- Number Of Decks
- 1
