Specifications
- Material Insulation
- Polyamide (PA), Nylon
- Montaj
- Through Hole
- Renk
- Gray
- Wire Gauge Min
- 10 AWG
- Tip
- Disconnect
- Terminal Stili
- Bolt and Nut
- Wire Gauge Max
- 26 AWG
- Uzunluk
- 91.4mm
- ECCN Kodu
- EAR99
- Genişlik
- 16.3mm
- Material Flammability Rating
- UL94 V-0
- Voltageiec
- 1000V
- Nominal Gerilim
- 1kV
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2011
- Wire Gauge Or Range Awg
- 10-26 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 41A
- Disconnect Type
- Switch, Slide
- HTS Kodu
- 8536.69.40.40
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.1-6mm2
- Parça Durumu
- Active
- Seri
- CLIPLINE RTO
- Fabrika Tedarik Süresi
- 15 Weeks
- Pozisyon Sayısı
- 2
- Number Of Levels
- 1
- Yükseklik
- 58.5mm
