Volume pricing
- 1+ pcs$4.35
- 10+ pcs$4.10
- 100+ pcs$3.87
- 500+ pcs$3.65
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 7 Weeks
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Insulation
- Polyamide (PA), Nylon
- Wire Gauge Or Range Awg
- 8-24 AWG
- Seri
- CLIPLINE UT
- Voltageiec
- 500V
- Currentiec
- 20A
- Gerilim
- 600V
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Disconnect Type
- Switch, Knife
- Flammability Rating
- UL94 V-0
- Stripping Length
- 10mm
- Wire Gauge Or Range Mm
- 0.2-10mm2
- Wire Gauge Min
- 8 AWG
- REACH Uyumluluk Kodu
- not_compliant
- Number Of Levels
- 1
- Akım
- 5A
- Yayın Yılı
- 2016
- Tip
- Disconnect
- Renk
- Gray
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Max
- 24 AWG
- Material Flammability Rating
- UL94 V-0
- Terminal Stili
- Screw
- Terminal Width
- 8.2mm
- Pozisyon Sayısı
- 2
