Volume pricing
- 1+ pcs$3.84
- 10+ pcs$3.62
- 100+ pcs$3.42
- 500+ pcs$3.23
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Insulation
- Polyamide (PA), Nylon
- Pozisyon Sayısı
- 2
- Number Of Levels
- 1
- Gerilim
- 600V
- Seri
- CLIPLINE UT
- Akım
- 16A
- Terminal Stili
- Screw
- Terminal Width
- 6.2mm
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 26 AWG
- REACH Uyumluluk Kodu
- not_compliant
- Wire Gauge Min
- 10 AWG
- Currentiec
- 20A
- Kurşunsuz Kodu
- yes
- Renk
- Gray
- Voltageiec
- 500V
- Tip
- Disconnect
- RoHS Durumu
- RoHS Compliant
- Stripping Length
- 9mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Wire Gauge Or Range Awg
- 10-26 AWG
- Yayın Yılı
- 2016
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.14-6mm2
- Disconnect Type
- Switch, Knife
- Fabrika Tedarik Süresi
- 7 Weeks
