Volume pricing
- 1+ pcs$0.75
- 10+ pcs$0.71
- 100+ pcs$0.67
- 500+ pcs$0.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Flammability Rating
- UL94 V-0
- Max Current Rating
- 41A
- Wire Gauge Max
- 26 AWG
- Uzunluk
- 47.7mm
- Nominal Gerilim
- 1kV
- HTS Kodu
- 8536.69.40.40
- REACH Uyumluluk Kodu
- unknown
- Wire Gauge Min
- 10 AWG
- Number Of Levels
- 1
- Seri
- CLIPLINE UT
- Gerilim
- 600V
- Akım
- 30A
- Weight
- 8.920007g
- Material Insulation
- Polyamide (PA), Nylon
- Wirecable Gauge
- 10 AWG
- ECCN Kodu
- EAR99
- Terminal Stili
- Screw
- Wire Gauge Or Range Awg
- 10-26 AWG
- Nem Hassasiyeti (MSL)
- Not Applicable
- Parça Durumu
- Active
- Akım Değeri
- 32A
- Kurşunsuz
- Lead Free
- Fabrika Tedarik Süresi
- 7 Weeks
- Yayın Yılı
- 2008
- Genişlik
- 6.2mm
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.14-6mm2
- Renk
- Red
- Voltageiec
- 1000V
- Tip
- Feed Through
- Stripping Length
- 9mm
- RoHS Durumu
- RoHS Compliant
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- Number Of Poles
- 2
- Currentiec
- 32A
- Kurşunsuz Kodu
- yes
- Orientation
- Straight
- Yükseklik
- 55mm
- Montaj
- Through Hole
