Specifications
- Housing Material
- Polyamide
- Wire Gauge Min
- 26 AWG
- Uzunluk
- 47.7mm
- Nominal Gerilim
- 1kV
- HTS Kodu
- 8536.69.40.40
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 26 AWG
- Max Current Rating
- 32A
- ECCN Kodu
- EAR99
- Terminal Stili
- Screw
- Wirecable Gauge
- 12 AWG
- Material Insulation
- Polyamide (PA), Nylon
- Weight
- 7.490001g
- Number Of Levels
- 1
- Gerilim
- 600V
- Seri
- CLIPLINE UT
- Akım
- 20A
- Yayın Yılı
- 2010
- Wire Gauge Or Range Mm
- 0.14-4mm2
- Genişlik
- 5.2mm
- Flammability Rating
- UL94 V-0
- Kurşunsuz
- Lead Free
- Fabrika Tedarik Süresi
- 7 Weeks
- Nem Hassasiyeti (MSL)
- Not Applicable
- Parça Durumu
- Active
- Akım Değeri
- 32A
- Wire Gauge Or Range Awg
- 12-26 AWG
- Yükseklik
- 55mm
- Montaj
- Through Hole
- Orientation
- Straight
- Currentiec
- 24A
- Kurşunsuz Kodu
- yes
- Voltageiec
- 1000V
- Renk
- Red
- Tip
- Feed Through
- RoHS Durumu
- RoHS Compliant
- Stripping Length
- 9mm
- Number Of Poles
- 2
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
