Volume pricing
- 1+ pcs$3.12
- 10+ pcs$2.95
- 100+ pcs$2.78
- 500+ pcs$2.62
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj
- Through Hole
- Safety Approval
- CSA; CUL; GL; IEC; KEMA; UL
- Kurşunsuz Kodu
- yes
- Renk
- Gray
- Voltageiec
- 800V
- Tip
- Feed Through
- RoHS Durumu
- RoHS Compliant
- Stripping Length
- 9mm
- Number Of Ways
- 4
- Onay Kuruluşu
- CSA, cULus
- Yayın Yılı
- 2008
- Genişlik
- 6.2mm
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.14-6mm2
- Sıra Sayısı
- 1
- Kurşunsuz
- Lead Free
- Fabrika Tedarik Süresi
- 7 Weeks
- Nem Hassasiyeti (MSL)
- Not Applicable
- Parça Durumu
- Active
- Akım Değeri
- 30A
- Wire Gauge Or Range Awg
- 10-26 AWG
- Number Of Decks
- 2
- ECCN Kodu
- EAR99
- Terminal Stili
- Screw
- Wirecable Gauge
- 10 AWG
- Weight
- 21.189993g
- Material Insulation
- Polyamide (PA), Nylon
- Pozisyon Sayısı
- 4
- Number Of Levels
- 2; Connected
- Gerilim
- 600V
- Seri
- CLIPLINE UTTB
- Akım
- 30A
- Wire Cross Section
- 6 mm2
- REACH Uyumluluk Kodu
- unknown
- Wire Gauge Min
- 26 AWG
- Uzunluk
- 69.9mm
- Nominal Gerilim
- 800V
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 26 AWG
